Laminated Glass is made up of two or more layers of glass permanently bonded together with an interlayer (PVB / SGP / EVA) via a controlled, highly pressurized and industrial heating process. The lamination process results in the glass panels holding together in the event of breakage, reducing the risk of harm. Laminated Glass is classified as Grade A Safety Glass. There is several laminated glass types manufactured using different glass and interlay options that produce a variety of strength and security requirements.
Inquire Now
FEATURES:
1) Extremely high safety: The PVB interlayer withstands penetration from impact. Even if the glass cracks, splinters will adhere to the interlayer and not scatter. In comparison with other kinds of glass, laminated glass has much higher strength to resist shock, burglary, burst and bullets.
2) Energy-saving building materials: PVB interlayer impedes the transmission of solar heat and reduces cooling loads.
3) Create aesthetic sense to buildings: Laminated glass with a tinted interlayer will beautify the buildings and harmonize their appearances with surrounding views which meet the demand of architects.
4) Sound control: PVB interlayer is an effective absorber of sound.
5)Ultraviolet screening: The interlayer filters out ultraviolet rays and prevents the furniture and curtains from fading effect
APPLICATIONS:
• Sloped/Overhead Glazing
• Museums, Prisons, Government Buildings
• Jewelry Stores, Banks, Airports
• Safety Glazing Applications
• Schools, Hospitals, Hotels
• Interior Partitions, Office Buildings, flooring
• Many Others.
SPECIFICATIONS:
PVB Color: Clear, Green, Blue, Bronze, Grey, Milk white,yellow,pink,purple etc.
Glass Color: Clear, Extra Clear, French Green, Dark Green, Ford Blue, Dark Blue, Bronze, Euro Grey etc. available with reflective glass also.
Regular Thickness:
3+0.38PVB+3mm; 4+0.38PVB+3mm; 5+0.38PVB+5mm; 6+0.38PVB+6mm;
3+0.76PVB+4mm; 4+0.76PVB+4mm; 5+0.76PVB+5mm; 6+0.76PVB+6mm,
8+0.76PVB+8+0.76PVB+8MM...ect.
Sizes:
1220 x 915mm, 1830 x 1220mm, 1830 x 2440mm,
1524 x 2440mm, 1650 x 2200mm, 1830 x 3050mm,
2134 x 3050mm, 2134 x 3300mm, 2134 x 3660mm,
2250 x 3300mm, 2440 x 3050mm, 2440 x 3660mm.
customized sizes and thickness acceptable.
